DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-58
29 October, 2019 IVEK Corp. P03R017E
Setup E Screen Description - The Setup E screen displays some additional settings for the Controller Module and
allows a user with Supervisor permission to change the parameters. The current permission level determines which
push-buttons are available as shown.
The Start push-button is not functional, but the Stop push-button is functional while this screen is visible.
LOGIC I/O Gateway - The LOGIC I/O Gateway when Enabled does not allow starts when a Link indicates Busy or
fault. The LOGIC I/O Gateway can either be Enabled or Disabled.
Aux Out 1 True - The Aux Out 1 True determines the conducting state of the Aux Out 1 signal. The output can either
be Conducting or Not Conducting when the output signal is True.
Aux Out 2 True - The Aux Out 2 True determines the conducting state of the Aux Out 2 signal. The output can either
be Conducting or Not Conducting when the output signal is True.
Output 1 True - The Output 1 True determines the conducting state of the Output 1 signal. The output can either be
Conducting or Not Conducting when the output signal is True.
Output 2 True - The Output 2 True determines the conducting state of the Output 2 signal. The output can either be
Conducting or Not Conducting when the output signal is True.
Output 3 True - The Output 3 True determines the conducting state of the Output 3 signal. The output can either be
Conducting or Not Conducting when the output signal is True.
Output 4 True - The Output 4 True determines the conducting state of the Output 4 signal. The output can either be
Conducting or Not Conducting when the output signal is True.
Recipe Out True - The Recipe Out True determines the conducting state of the Recipe Out signals. The outputs can
either be Conducting or Not Conducting when the output signal are True.
