IVEK DIGISPENSE 3009 - Page 92

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-92
29 October, 2019 IVEK Corp. P03R017E
c => CLEAR FAULTS
c or c0 c0,<value2> Clears all faults and reference pumps.
d => DIRECTION
d or d0 d0,<value2> Returns current Production Mode fluid direction setting.
d0,<value2> d0,<value2> Sets the Production Mode fluid direction.
<value2>:
0 = Reverse
1 = Forward (default)
d1 d1,<value2> Returns current Fluidic Mode direction setting.
d1,<value2> d1,<value2> Sets the Fluidic Mode direction.
<value2>:
0 = Reverse
1 = Forward (default)
e => END
e or e0 e0 Ends the current pumping cycle.
In Prime mode, will continue until piston has reached the stop position.
f => REFERENCE
f or f0 f0 References the pump.
g => TOTALIZER
g or g0 g0,<value2> Returns the totalizer value in number of Strokes.
g0,<value2> g0,<value2> Resets the totalizer value to 0.
<value2>: 0 = Resets the totalizer value to zero.
g1 g1,<value2> Returns the totalizer value in number of Cycles.
g1,<value2> g1,<value2> Resets the totalizer value to 0.
<value2>: 0 = Resets the totalizer value to zero.
g2 g2,<value2> Returns the last prime volume/agitate volume read in strokes.
MAX VALUE: The totalizer will increment to a maximum value of 3,999,999,999 then 'wrap around’.
h => HARDWIRED READY SIGNAL OPERATION
h1 h1,<value2> Returns the Controller address for serial interface setting.
h1,<value2> h1,<value2> Sets the Controller address for serial interface configuration.
<value2>
1 = Minimum (default)
99 = Maximum
h2,<value2> h2,<value2> Sets the contrast percentage.
<value2>
30 = Minimum
50 = (default)
70 = Maximum
h3,<value2> h3,<value2> Enables/Disables Comm Gateway mode.
<value2>
0 = Disabled (default)
1 = Enabled)
h4,<value2> h4,<value2> Enabled/Disabled Logic I/O Gateway mode.
<value2>
0 = Disabled (default)
1 = Enabled
h5,<value2> h5,<value2> Configures the conduction level for Recipe Outputs when 'true'..
<value2>
0 = Recipe Outputs conducting when 'true'.
1 = Recipe Outputs non-conducting when 'true'.
h10 h10,<value2> Returns the Input CC 1 setting.
h10,<value2> h10,<value2> Sets the Input CC 1 configuration.
