<value2>
0 = <TRIGGER> Fault Clear & Reference
1 = <TRIGGER> Fluidic Operations
2 = <LOCK> Motion
3-8 = <LOCK> Front Panel
9 = Reserved
10 = Reserved
11 = <TRIGGER> Production Operations (default)
12 = <LINK> With Output
13 = <DISABLED>
h11 h11,<value2> Returns the Input 1 setting.
h11,<value2> h11,<value2> Sets the Input 1 configuration.
<value2>
0 = Same as h10, default = <TRIGGER> Production Ops
h12 h12,<value2> Returns the Input 2 setting.
h12,<value2> h12,<value2> Sets the Input 2 configuration.
<value2>
Same as h10, default = <TRIGGER> Fluidic Ops
h13 h13,<value2> Returns the Input 3 setting.
h13,<value2> h13,<value2> Sets the Input 3 configuration.
<value2>
Same as h10, default = <TRIGGER> Clear Fault & Reference
h14 h14,<value2> Returns the input 4 setting.
h14,<value2> h14,<value2> Sets the input 4 configuration.
<value2>
Same as h10, default = <DISABLED>
h19 h19,<value2> Returns the input CC 2 setting.
h19,<value2> h19,<value2> Sets the Input CC 2 configuration.
<value2>
Same as h10, default = <DISABLED>
h20 h20,<value2> Returns the Aux Out 1 setting.
h20,<value2> h20,<value2> Sets the Aux Out 1 configuration.
<value2>
0 - <DISABLED> (default)
1 - <BUSY> Discharge
2 - <BUSY> Production Operations
3 - <BUSY> All Operations
4 - <READY> Idle
5 - <READY> Production
6 - <STATUS> Reference
7 - Reserved
8 - Reserved
9 - <BUSY> Fluidic Operations
10 - <BUSY> Production & Fluidic Operations
11 - <SUCCESS> Last
12 - <SUCCESS> Pulse
13 - <LINK> With Input
14 - Reserved
15 - <BUSY> AP Prime
16 - <STATUS> Fault
h21 h21,<value2> Returns the output 1 setting.
h21,<value2> h21,<value2> Sets the output 1 configuration.
<value2>
Same as h20, default = <READY> Production
h22 h22,<value2> Returns the output 2 setting.
h22,<value2> h22,<value2> Sets the output 2 configuration.
<value2>
Same as h20, default = <STATUS> Fault
