24
CW HW
2. Designation of the components
All heat exchangers of long-wave stainless steel corrugated pipes DN 25 d
a
32.8mm, connections G 1¼".
Heating heat exchanger
Solar Heat Exchanger
Latent material
Solar riser tube
Storage tank + insulation
(of PP/PU/PP)
Fill and drain valve with ½"
KFE-plug valve
Electrical heating
element (optional)
Temperature and
filling level display
Sensor Sleeves for
Temperature Sensors
Cover of storage
tank (of PP/PU/PP)
Drinking water heat exchanger
Illustrations similar
