IVT LATENTO XXL Series User Manual

39
E
* DIN 4708-3 (reheating 60 kW)
WP-S 500
Container
Material of internal container Polypropylene
Material of Polypropylene
Material of insulation Polyurethane
Length (l) 78 cm
Width (w) 78 cm
Height (h) 158 cm
Tilted size 176 cm
Empty weight 105 kg
Weight with Latent Material 125 kg
Nominal capacity, storage water 536 l
Mean temperature decrease per hour 0,1 K/h
Max. storage tank temperature 85 °C
Tapping rating (65 °C storage temperature)
without re-heating
330 l
Continuous rating (85 °C re-heating) 1700 l/h
Continuous output of hot water Q
D
(85/10/45)
69 kW
Performance characteristics N
L
*
10*
Solar heat exchanger
Long-wave stainless steel corrugated pipe
DN 25 (ø 32.8 x 0.3 mm)
Length 14 m
Surface 2,2 m²
Water content 9,8 l
Connection G 1¼
Drinking water heat exchanger
Long-wave stainless steel corrugated pipe
DN 25 (ø 32.8 x 0.3 mm)
Length 39,3 m
Surface 5,7 m²
Water content 27,5 l
Connection G 1¼
Heating heat exchanger
Long-wave stainless steel corrugated pipe
DN 25 (ø 32.8 x 0.3 mm)
Length 27,3 m
Surface 4,0 m²
Water content 19 l
Connection G 1¼
