FAA Approved Installation Manual for the Report No 908
EDM-900 and EDM-930 Page 32 of 56 Rev I
Primary Engine Data Management System Date 1-18-2013
31. Component Parts
Single engine
-4 Cyl -6 Cyl -7 Cyl -8 Cyl -9 Cyl
Display EDM-930 P/N 790000-C-(xxx) 1 1 1 1 1
Display EDM-900 P/N 790000-A-(xxx) 1 1 1 1 1
EGT probe KIT 12800 4 6 7 8 9
TIT probe with option KIT 12000 1 1 1 1 1
CHT probe KIT 12600 4 6 7 8 9
OAT probe with option KIT 12200 1 1 1 1 1
IAT probe with option KIT 11200 1 1 1 1 1
Carb temp probe if required KIT 11900 1 1 1 1 1
Oil temperature probe with KIT 124000 P/N 400409 1 1 1 1 1
Oil pressure sender KIT 14600 P/N 159936A 1 1 1 1 1
Fuel pressure sender KIT 145000 P/N 159935A 1 1 1 1 1
Fuel pressure differential sender KIT 148000 P/N159938 1 1 1 1 1
Ammeter shunt P/N 159920 KIT 13000 1 1 1 1 1
Fuel Flow transducer P/N 700900-1,-2 1 1 1 1 1
Fuel Level sender option P/N 791000 1 1 1 1 1
MAP P/N 159934A Kit 14400 1 1 1 1 1
RPM one of P/N 420815-1,-2 1 1 1 1 1
RAD P/N-790749 for use with the EDM-930 1 1 1 1 1
Alarm light PN 790547 for use with the EDM-900 1 1 1 1 1
31.1 Component Parts List for EGT KIT 12800, TIT KIT 120000
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp Thimble
1 Stainless Steel Exhaust Seal Washer
1 Stainless Steel Screw Type Clamp
2 Ring Terminals
2 Screws and nuts 6-32 X 1/4
1 Fiberglass tube 3/8”X 5”
31.2 Component Parts list for CHT KIT 12600
1 Bayonet Probe Thermocouple type K Spring loaded PN 5050-T
1 Or Gasket thermocouple probe type K PN MM-113
2 Ring Terminals
2 Screws and Nuts 6-32 X 1/4"
1 Fiberglass tube 3/8”X 5”
31.3 Component Parts list for OAT KIT 12200
1 P/N 400510, OAT probe
2 Ring Terminals
2 Screws and Nuts 6-32 X1/4"
Fiberglass tube 3/8”X 5”
31.4 Component Parts list for IAT KIT 11400
1 Thermocouple type K probe PN M-111
1 Stainless Steel Clamp & Thimble
1 Stainless Steel Exhaust Seal Washer
