5 INSTALLATION AND COMMISSIONING
5.1 Unpacking the machine:
Machines are delivered from our works on pallets, strapped and protected with cardboard. First of all,
the packaging must be examined and any damage caused in transit must be declared directly to the
carrier.
A. Remove the cardboard and the packaging bag from the machine.
B. Remove straps, taking particular care when they are released by cutting.
C. Detach the machine from its pallet by removing the wooden battens wedging the feet.
D. Take the machine off the pallet. Make sure you do this with at least two people in order to
lower it as gently as possible onto the floor.
E. Please fit the adjustable bagger stop to the bagger (fig.10, n°8).
After unpacking your machine, check that it has not been damaged in transit. Notify
us of any defects.
If your machine has been supplied with a base (optional):
A. Fit the castors supplied to the base, taking care to fit the braked castors at the front.
B. With at least two people, place the machine on the base.
C. Remove the crumb tray from the machine.
D. Insert the silent block bushes supplied between the machine and the base (fig.4, n°21).
E. From the inside of the machine, insert the screws (fig.4, n°20) and washers supplied into the
corresponding holes in the machine frame.
F. Pass the screws through the machine, the silent block bushings and the base and tighten the
assembly with the nuts supplied (fig.4, n°22).
5.2 Positioning:
In order to achieve excellent performance and long-term reliability, choose a location that is:
Well ventilated, shielded from direct sunlight and away from sources of heat, with a sturdy
surface free from vibration.
5.3 Electrical connection:
IMPORTANT: This machine must be earthed.
It is recommended that the system be protected with a fuse and an RCD.
Your mains electricity supply to the machine must be protected as indicated below:
