S5 Workshop Manual Engine
EM-55
Descriptions
Defect Condition
4. The teeth is worn seriously
(preliminary)
5. Belt tooth is worn seriously (late
period).
6. Tooth root cracks.
7. Flex cracking
8. Belt side has serious abrasion.
9. Belt side cracks.
Canvas exposed in force borne surface
(canvas has burrs, rubber grinds into
white, and texture of canvas is unclear.
Side abrasion of the
tooth (on force
borne surface)
Side abrasion of the tooth, and rubber exposes on
force borne surface (tooth width reduces)
Rubber exposes
Crack
Lack of teeth and
canvas fiber exposes
Side of arch belt
Abnormal abrasion
(Canvas has burrs)
