S5 Workshop Manual Engine
EM-67
Safety spring
Free length
When loading [61 N],
46.6 mm
40.1 mm
Item
Specification parameter
Limiting value
Left balance shaft
Rear journal diameter
Rear journal diameter
Clearance
Front
Rear
Balance shaft
Rear journal diameter
Rear journal diameter
Clearance
Front
Rear
18.467 18.480 /41.959 - 41.975
mm
40.951 40.967 mm
0.020 0.061 mm
0.050 0.091 mm
18.467 18.480 mm
40.951 40.967 mm
0.020 0.054 mm
0.042 0.083 mm
Cooling type
Water cooling
Cooling system capacity
4.0 L
Thermostat
Type
Normal opening temperature
Opening temperature range
Full open temperature
Paraffin type
82
80 84
95
Radiator cover
Main valve open pressure
Main valve close pressure
Opening pressure of vacuum
valve
107.9 ± 14.7 KPa
(1.1 ± 0.15 kg/cm²,15.64 ± 2.13 psi)
83.4 KPa (0.85 kg/cm², 12.1 psi)
-6.86 KPa (-0.07 kg/cm², -1.00psi)
Air exhaust pipe
Muffler
Suspension system
Expansion series resonant
Rubber suspension device
Coolant temperature sensor
Type
Resistance
20
80
Thermistance type
2.45 ± 0.14 KΏ
0.3222
