Jack C4 User Manual

11
P28
INTARZIERE TAIERE –
ANTITAIERE
MATERIAL
Delay stitches number of
anti‐cutting the cloth
0 - 50
8
Cu cat este mai mica valoarea cu atat va
fi mai mica ata la material
The smaller of the value, the shorter of
the thread length on the cloth will be
P29
前剪线吸风开启针数
front trimming suction
open thread number
1- 50
1
电机运行后经过P29，前剪线吸风开启
After the motor running to P29, front
trimming suction opening
P30
前剪线吸风关闭针数
front trimming suction
close thread number
0 - 250
0
（P60≠2）
0：前剪线吸风与前剪线同步关闭
其他：前剪线吸风开启后经过P30针数
关闭
0：front trimming suction and front
trimming synchronous closing
Other：when after front trimming suction
opening go by P30，thread number
closing
25
（P60=2）
P31
后剪线吸风关闭延时
Delay time after back
suction off
1 - 50
8
（*100 ms）
P32
防切布传感器开关
sensor for anti‐cutting the
cloth switch
0 - 1
1
（P60≠2）
0：关闭off
1：开启on
0
（P60=2）
P33
SENSIBILITATEA
SENZORULUI ANTI
TAIERE MATERIAL
Sensitivity of sensor for
anti‐cutting the cloth
20 - 40
36
Cu cat valoarea este mai mare cu atat este
mai mare posibilitatea de a identifica
materiale translucide
The bigger of the sensitivity parameter,
the more capable to identify translucent
materials
P34
NUMAR DE
IMPUNSATURI INTRE
SENZORUL DIN SPATE
SI CEL ANTI TAIERE
MATERIAL
Stitch number between
back sensor and sensor
for anti‐cutting the cloth
1 - 200
99
P35
停车延迟针数
Delay stitch number
when stop sewing
1 - 99
5
（P60≠2）
35
（P60=2）
P36
后剪线吸风开启针数
back trimming suction
open thread number
1 - 50
3
P37
SENSIBILITATE
SENZOR FATA
Sensitivity of front
sensor
20 - 40
36
Cu cat este mai mare valoarea cu atat este
mai capabil sa identifice materiale
translucide
The bigger of the sensitivity parameter, the
more capable to identify translucent

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
