Jack C4 User Manual

12
materials
P38
SENSIBILITATE
SENZOR SPTE
Sensitivity of back sensor
20 – 40
36
Cu cat este mai mare valoarea cu atat este
mai capabil sa identifice materiale
translucide
The bigger of the sensitivity parameter, the
more capable to identify translucent
materials
P39
前抬压脚保持时间
Delay time before presser
foot lifter
1- 50
2
（*100ms）
P40
后抬压脚启动时间
Start time after presser
foot lifter
0 - 20
0
（*100 ms）
P41
压脚全出力时间
Full output time of
presser foot
1 - 50
10
（*10 ms）
P42
压脚出力周期信号
Periodic signal of presser
foot output
0 - 50
15
（/10 ms）开通时间，总周期5MS
Turn-on time, total cycles 5MS
P43
压脚下放时间
Time of presser foot put
down
1 - 99
10
（*10 ms）
P44
压脚保护时间
Time of presser foot
protection
1 - 20
5
S
P45
剪线时间
Time of trimmer
1 - 100
40
P46
连续送布吸气
Continuous feeding and
suction
0 - 2
2
0：关闭吸屑
1：连续吸屑
2：吸屑与剪线吸气同步
0：Closed suction crumbs
1：Continuous suction crumbs
2：Suction crumbs and trimming suction
in sync
P47
BUTONUL MANUAL
DE TAIERE ATA
Manual trimmer switch
0 - 1
1
0：oprit
1：pornit
P48
GASIREA POZITIEI DE
AC SUS AUTOMATA
Automatically find up
positioning
0 - 1
0
0：oprit
1：pornit
P49
压脚关闭周期信号
Periodic signal of presser
foot closed
0 - 50
35
（/10 ms）关闭时间，总周期5MS
Turn-off time, total cycles 5MS

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
