Jack C4 User Manual

10
P14
手动吸气
Manual suction switch
0 - 2
0
0：关闭off
1：后吸rear suction
2：前后吸front suction and rear suction
P15
机头灯开关
Head lamp switch
0 - 3
1
0：关闭 off
1-3：开启on
P16
休眠功能开关
Dormancy function
0 - 1
1
0：关闭 off
1：开启on
P17
半智能连续缝制
Semi‐automatic constant
rate trimming
0 - 2
2
0：关闭 off
1：前踏可连续缝制Front step
continuous sewing
2：连续缝纫，忽略前传感器使能开关
Constant sewing and ignore the front
sensor switch
P18
半智能恒速剪线
Semi‐automatic constant
rate trimming
0 - 1
1
0：关闭 off
1：固定前剪线前运行速度fix the
machine speed when front thread trimmer
P19
下位机版本号
Program version No.
V**
电控软件版本号
Control box software version number
P20
上位机版本号
PC version No.
V**
面板软件版本号
Panel software version number
P21
用户常用参数
User common parameters
0 - 1
0
0：无操作no operation
1：保存参数为用户常用参数
saving parameters into user common
parameters
P22
前传感器开关
Front sensor switch
0 - 1
1
0：关闭off
1：开启on
P23
前吸风打开时间
Opening time of manual
suction
1 - 250
5
前吸风打开时间（*100 ms）
Opening time of manual suction
P24
吸风关闭时间
Turn off time of suction
0 - 250
0
前吸风关闭时间（*100 ms）
Time when front suction off
P25
SENZOR SPATE
Back sensor switch
0 - 1
1
0：oprit
1：pornit
技术员区：同时按住“P”键和“抬压脚”键进入Technician parameter：Press P button and Enter button
at the same time to enter
P26
NUMAR DE
IMPUNSATURI INTRE
SENZORUL DIN FATA
SI CEL DIN SPATE
1 - 250
100
P27
LUNGIMEA ATEI
DUPA TAIERE
The delay stitches
number of trimmer
before sewing
0 - 10
2
Cu cat este mai mare valoarea cu atat mai
scurta va fi ata dupa taiere
The bigger of the value, the shorter of the
thread length will be after cut

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
