Jack C4 User Manual

9
用户区：按住“P”键1.5秒进入User parameters：Press P button for 1.5seconds to enter
P1
VITEZA MAXIMA
500 - 7000
6000
RPM
P2
POZITIONARE AC
0 - 2
1
0：fara pozitionare
1：ac orpit sus
2：ac oprit jos
P3
VITEZA MAXIMA LA
START
500 - 7000
5500
RPM
P4
MOD DE PORNIRE
0 - 1
0
0：mod automat
1：control la pedala
P5
SELECTARE MOD DE
LUCRU
0 - 2
1
0：manual
1：semiautomat
2：full automat
P6
REGLARE VOLUM
VOCE
0 - 3
2
0：oprire 1-3 pornit
P7
TAIERE AUTOMATA
0 - 3
3
0：oprit
1：taiere inainte de coasere
2：taiere dupa coasere
3：taiere inainte si dupa coasere
P8
自动吸气
Auto suction
0 - 3
1
（P60≠2）
0：关闭 off
1：前剪线吸气开suction when trimmer
before sewing
2：后剪线吸气开suction when
trimmerafter sewing
3：前后剪线吸气开suction when
trimmer before and after sewing
3
（P60=2）
P9
反踏剪线开关
Counter pedal trimmer
0 - 1
1
0：关闭off
1：开启on
P10
RIDICARE
AUTOMATA A
PICIORUSULUI
0 - 3
0
0：oprit
1：ridicare inainte de coasere
2：ridicare dupa coasere
3：ridicare si la inceput si la sfarsit de
coasere
P11
PICIORUSUL SE
RIDICA CAND SE
OPRESTE COASEREA
0 - 1
0
0：oprit
1：pornit
P12
RIDICARE PICIORU
DUPA TAIERE
0 - 1
0
0：oprit
1：pornit
P13
NUMARARE
RIDICARE PICIORUS
Semi‐counter presser foot
lifter
0 - 1
1
0：oprit
1：pornit

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
