Jack C4 User Manual

14
P67
后传感器档位调节
Adjusting gear of back
sensor
10 - 90
--
参数值越大，传感器电压值越大
The greater the parameter values,The
greater the voltage value of the sensor
P68
防切布传感器档位调节
Adjusting gear of sensor
for anti‐cutting the cloth
10 - 90
--
参数值越大，传感器电压值越大
The greater the parameter values,
The greater the voltage value of the sensor
P69
计件数计数单位
Unit number counting
1 - 50
10
设置每件剪线次数
Setting per unit trimmer number
P70
计件数总数设定
Total counting setting
1-9999
100
P71
计件数计数模式
Counting mode
0 - 5
0
0：关闭；off
1：升序循环计数；ascending cycle
count
2：降序循环计数；descending cycle
count
3：升序计满报警；ascending full alarm
4：降序计满报警；descending full
alarm
5：清除计满报警；remove full alarm
P72
强制后剪线延迟针数
The stitches number of
constraint back trimmer
0 - 20
9
布料前剪线后离开前、后感应器且未
遮住第三感应器经过设定针数后执行
后剪线。
Adjust the back trimmer function even the
fabric does not cover the anti-cutting
sensor, can adjust the stitches number
before the trimmer function active
系统员参数（P+上键，设置三位密码“111”，按“P”进入）
Member of the system parameters （P+up key，Set up three passwords“111”，press“P”to enter
）
P81
同步吸气，前吸屑关闭
针数
Synchronous inspiratory
， front suction crumbs
close thread number
0 - 250
0
0：前吸屑与前剪线吸气同步关闭
其他：前吸屑开启P81针数后关闭，但
不能比前剪线吸气提前关闭。
0：front suction crumbs and front
trimming inspiratory synchronous closing
Other：when after front suction crumbs
opening go by P18，thread number
closing，but can't shut down earlier than
front trimming inspiratory
P82
同步吸气，后吸屑关闭
针数
Synchronous inspiratory
， back suction crumbs
0 - 250
0
0：后吸屑与后剪线吸气同步关闭
其他：后吸屑开启P82针数后关闭，但
不能比后剪线吸气提前关闭。
0：back suction crumbs and back

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
