Jack C4 User Manual

15
close thread number
trimming inspiratory synchronous closing
Other：when after back suction crumbs
opening go by P82，thread number
closing，but can't shut down earlier than
back trimming inspiratory
P83
前剪线松线电磁阀开启
针数
Front trimming loose line
solenoid valve open
thread number
0-50
1
0：前剪线松线电磁阀关闭
其他：前剪线松线电磁阀经(P83)-1针
数开启
0:Front trimming loose line solenoid valve
opening
Other:Front trimming loose line solenoid
valve go by (P83)-1 open thread number
P84
前剪线松线电磁阀关闭
针数
Front trimming loose line
solenoid valve close
thread number
1-50
1
P85
后剪线松线电磁阀开启
针数
back trimming loose line
solenoid valve open
thread number
1-50
1
0：后剪线松线电磁阀关闭
其他：后剪线松线电磁阀经P85针数开
启
0:back trimming loose line solenoid valve
closing
Other:back trimming loose line solenoid
valve go by P85 open thread number
P86
后剪线松线电磁阀关闭
针数
back trimming loose line
solenoid valve close
thread number
1-50
10
P87
手动吸气持续时间
Duration time of manual
suction
1-50
3
(*100ms)
P88
手动吸气电机转速
Speed of manual suction
motor
500 - 7000
3500
注7：系统员参数
1、 说明书未提及参数，请勿随意更改！
2、 按P+上键，面板显示“000”，分别按 进行密码设置。
Note 7：Member of the system parameters
1、PARAMETRII CARE NU SUNT TRADUSI A NU SE SCHIMBA !!
2、

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
