1.2 INTRARE IN PARAMETRII
Se apasa lung （ ）pentru 1,5 sec si masina va intra in modul de
setare parametrii. Se apasa butonul de stanga（ ）si de dreapta（ ）
pentru a modifica numarul parametrilor. Se apasa butonul ）si ）
pentru a modifica valoarea paramtrului. S e apasa butonul de Enter pentru
salvare.
2. SETAREA PARAMETRILOR
2.1 Setarea in mod :
Automatic/ Semi‐automatic/ Manual
Apasand butonul （ ）,se poate modifica modul de coasere – apasand pe
acest buton modul de coasere se schimba ciclic astfel : Automatic/ Semi‐automatic/
manual. Se apasa butonul（ ）pentru confirmare si finalizare setare. Nu se apasa
timp de 5 secunde daca doriti intoarcere la interfata masinii si nu doriti salvarea
parametrului.
注1：参数关联
Note1：Parameter association
在对应模式修改P1最高转速、P3起缝速度、P10自动抬压脚、P17半智能连续缝制、P27
前剪线延迟针数、P28后剪线延迟针数、P50防切布传感器延迟针数值时，只更改当前模式下
的值，模式切换后，对应参数值同步到当前模式下的参数值。
When modify the parameter in the corresponding mode P1 Max rotate speed、P3 Start sewing
speed、P17 Semi‐automatic constant rate trimming、P27 The delay stitches number of trimmer
before sewing 、P28 delay stitches number of anti‐cutting the cloth、P50 the delay stitches number
of trimmer after sewing, It only can modify the current mode value, after mode switch, the
parameters correspond the value in the current mode.

Jack C4 Specifications

General

Product Introducti	ion-technical specifications
Type/Name	C4 The Fastest Automatic Overlock Machine
Highest Speed	7000rpm/min
Differential	0.7-2.0
Thread Wideth（mm）	1.5-8.0
Presser Foot Height（mm）	5.0-7.0
Needle Type	DCX27
Needle Bar Height	（general）10.4mm/12mm（heavy）
Needle Bar Stroke	（general）24.5mm/26mm（heavy）

Weight and Dimensions

Max Length(mm)	0.8-4.8
