Install governor rod should guarantee the rod
position is perpendicular to the pedal.
Adjustment rod former high and behind low
angle to make the pedal angle relative to the
ground plane 15 degrees is advisable. (Picture 1
and picture 2 )
II. OPERATION INSTRUCTION OF OPERATION PANEL
In P interface, the first tube display “P”, the second tube display “-” (means bottom position).
1.1 Speed Adjust
The panel shows “P”, then press “+” or ”-” to adjust speed up and down. After 3 seconds, the
parameter saved the panel back to the “p”. For example, 35 means 3500rmp/min.
1.2 Needle Position Adjust
The panel shows “P”, press “+” for 3 seconds, then set the position up or down.
