(1)The installation of plastic reservoir
1)Firstly, oil pan holder③and Oil pan cushion②should be set in the four corners of the oil pan
①，and then install the oil pan①on the stand & table.
2)As is shown in the chart, making sure that the two oil holders①are pointing to the operator
during the installation and the two oil pan cushions② are on the side which is with machine
head connecting hook⑤.
3)Install the machine head connecting hook base④on the stand & table, and then put the
machine head connecting hook ⑤ in the baseplate hole, at last,put the head on the stand table,
making sure machine head connecting hook ⑤ is nested in the machine head connecting hook
base ④ which is on the stand & table.
3.膝动提升高度的调整/ADJUSTING THE HEIGHT OF THE KNEE LIFTER
2) 调节膝动提升调节螺丝①可以把压脚高度最大调整到13mm。
3) 压脚提升到10mm以上时，请注意针杆②的前端下降到最底下，不能碰到压脚 ③ 。
1) The standard height of the presser foot lifted using the knee lifter is 10mm.
2) You can adjust the presser foot lifted up to 13mm using knee lifter adjust screw ① .
3) When you have adjusted the presser foot lift to over 10mm,be sure that the bottom end of
1）请把New Defrix No.10机油倒进油槽①里，一直加到HIGH
标记A的位置。
2）油槽的油面降到LOW标记B以下时，请再次补充机油。
3）加油后运转缝纫机，如果润滑正常，可通过油窗②
※油流动量的多少，与油量的多少无关。
※新机器使用1个月后请更换机油，后期每六个月更换机油。
新缝纫机或较长时间没有使用的缝纫机在使用之前，应进行10分钟2500-3000rpm
的磨合运转。
When you first operate your machine after seter or after an extended period of
disuse, run your machine at 2,500 to 3,000 rpm .for about 10 minutes for the
purpose of break-in.
