33 / 51
when lower cutter component reset, distance between component tool
rest of the lower cutter and incised edge of lower cutter is 4 mm (figure 4),
if the above conditions can't meet at the same time,then need to loosen nut
1 and nut 2 to adjust the process of shearing electromagnet, by adjusting
he process of shearing electromagnet to meet the requirements of the
above regulation, standard of shearing electromagnet is 20 mm (figure 3).
Figure 1
Figure 2
disk drive connecting rod
