Jackson JPX-300H - JPX-300 L Dimensions

JPX-300 Installation/Operation Manual 7610-002-71-26 Rev. J
Issued: 03-09-2006 Revised: N/A
SECTION 1: SPECIFICATION INFORMATION
JPX-300L DIMENSIONS
6
2-
1
2
"
Minimum
Wall
Clearance
22-5/8"
33-1/4"
24"
C
B
12"
D
C
19"
D
B
A
E
3-3/4"
8-1/2"
6-3/8" 3-7/8"
12-13/16"
12 13/16”
(84.5 cm)
LEGEND
A - Detergent Feeder Connection
B - Electrical Connection
C - Water Inlet 1/2” Female Pipe Thread, 2 1/2”
AFF
D - Rinse Additive Connection
E - Drain Connection Flexible Hose 6’ Free
Length, 1” ID x 1 3/8” OD
DIMENSIONS
Height (minimum): 33 1/4” (84.5 cm) Inside Clearance Height: 14 1/2” (36.8 cm)
Height (maximum): 34 1/4” (87 cm) Inside Clearance Width: 20 1/4” (51.4 cm)
Width: 24” (60.9 cm) Inside Clearance Depth: 21 1/4” (54 cm)
Depth: 22 5/8” (57.5 cm) Door Open Depth: 39 1/2” (100.3 cm)
Wall Clearance (minimum): 2 1/2” (6.4 cm)
*All dimensions are for reference only and are subject to change without notice.
24”
(60.9 cm)
22 5/8”
(57.5 cm)
19”
(48.3 cm)
3 3/4” (9.5 cm)
3 7/8”
(9.8 cm)
33 1/4”
(84.5 cm)
24”
(61 cm)
8 1/2”
(21.6 cm)
3 3/4”
(9.5 cm)
3 7/8”
(9.8 cm)
