51
> Change from previous revision
LF 4675 / LF 4677
Item Part No. Qty. Description Serial Numbers/Notes
1
3006981 2 Tire
2 1003638 2 Rim
3 360111 2 Inflation Valve
4 361648 6 Washer, Thrust
5 361647 2 Bearing, Thrust
6 471214 2 Fitting, Grease
7 461393 2 Pin, Spring 1/4 x 2”
8 117139 1 Steering Axle
9 363562 4 • Bushing
10 340491 1 Cylinder, Steering
557621 1 • Seal Kit - Gold Star Used on Gold Star Cylinders Only
5003658 1 • Seal Kit - HDM Used On HDM Cylinders Only
11 443840 2 Nut, 1-12 Hex Jam
12 452022 1 Flat Washer, 1
13 366789 1 Spacer, Axle
14 460064 1 Cotter Pin, 1/4 x 1-1/2”
15 460026 4 Cotter Pin, 1/8 x 3/4”
16 153234 2 Ball Joint
400194 2 • Screw, 5/16-18 x 1-3/4”
444718 2 • Locknut, 5/16-18 Hex
17 445666 2 • Nut, 1/2-20 Slotted Hex
18 1002032 1 Ball Joint, Right Hand Thread
19 1002031 1 Ball Joint, Left Hand Thread
471214 4 • Grease Fitting
20 445647 2 • Nut, 3/8-24 Slotted Hex
21 443120 1 Nut, 1/2-20 Hex Right Hand Thread
22 445664 1 Nut, 1/2-20 Hex Left Hand Thread
23 3009378 1 Tie Rod
24 460032 2 Cotter Pin, 1/8 x 1-1/2”
25 2000012 2 Hub, Wheel
26 353914 8 Wheel Bolt
27 367350 2 Washer, Thrust
28 2812202 1 Arm, Left Steering
29 2812201 1 Arm, Right Steering
30 446154 14 Lockwasher, 1/2 Heavy
31 400406 6 Screw, 1/2-13 x 1-1/4” Hex Head
32 2000057 2 Motor Mount
33 390859 2 Wheel Motor, 2000 Series See 50.1
34 554780 2 • Key
35 554779 2 • Nut
36 400410 8 Screw, 1/2-13 x 1-3/4” Hex Head
37 361451 2 Washer, Thrust
38 471227 1 45° Grease Fitting
To Next Page
