QUICK START GUIDE
en-13
VISUAL DISPLAY
ENGINE START
When the key switch is turned to the start’
position and the interlocks are set, this
screen is shown.
To start the engine, the parking brake must
be applied, the mow switch must be in the
off position and the foot pedal must be in the
neutral position. When the glow plug timer
ends, the engine will start.
The two LED lamps will flash green if the all
of the above conditions have been met.
ENGINE WILL NOT START
When the ignition key is turned to the start
position and the interlocks are not set, this
screen is shown.
• The parking brake is not applied.
• Mow switch is not in the OFF position.
• The foot pedal is not in the neutral
position.
The engine will not start until all the
items in the list are correct.
The two LED lamps will flash red until the
above conditions have been corrected as
detailed under engine start.
WARNING SLOPE ANGLE 17
°
During work if the machine is driven on a
slope greater than 17° the screen will display
this warning. This over rides all other infor-
mation, and will continue until the machine
has been driven to an area with a slope of
less than 17°.
WARNING OIL PRESSURE FAULT
When this screen is shown, the engine oil
pressure has decreased below the normal
level. If this happens during operation, Stop
the engine and check the oil level. Top up if
necessary. If the problem persists consult
your service dealer.
Press the select button to confirm the
fault.
