Jacobsen AR530 User Manual

3 LABELS
en-14
3.2 INSTRUCTION LABELS
Description
A 4117468 105 dB Guaranteed Sound Power Level
B 4381826 Traction Pedal
C 692776 Front HOC
D 675163 Rear HOC, LH
105
dB
L
WA
A
B
C
D
4381826
692776
19 mm 0.75 in 1
HK
25 mm 1.00 in 2
32 mm 1.25 in 3
38 mm 1.50 in 4
44 mm 1.75 in 5
51 mm 2.00 in 6
57 mm 2.25 in 7
64 mm 2.50 in 8
70 mm 2.75 in 9
76 mm 3.00 in 10
83 mm 3.25 in 11
89 mm 3.50 in 12
95 mm 3.75 in 13
102 mm 4.00 in 14
108 mm 4.25 in 15
114 mm 4.50 in 16
K
H
15 12
14
16
13
10
11
9
8
6
7
5
4
2
1
3
675163
19 mm 0.75 in 1
HK
25 mm 1.00 in 2
32 mm 1.25 in 3
38 mm 1.50 in 4
44 mm 1.75 in 5
51 mm 2.00 in 6
57 mm 2.25 in 7
64 mm 2.50 in 8
70 mm 2.75 in 9
76 mm 3.00 in 10
83 mm 3.25 in 11
89 mm 3.50 in 12
95 mm 3.75 in 13
102 mm 4.00 in 14
108 mm 4.25 in 15
114 mm 4.50 in 16
H
K
1
2
3
4
8
7
6
5
9
10
11
12 16
15
14
13

Jacobsen AR530 Specifications

General

Brand	Jacobsen
Model	AR530
Category	Lawn Mower
Language	English
