SPECIFICATIONS 11
en-91
11Specifications
11.1 ENGINE SPECIFICATION____________________________________________________
Model: V2403-E4B-T4I
Type: Vertical, water-cooled, 4-cycle diesel engine
Number of Cylinders 4
Bore and Stroke 3.43 x 4.03 inch (8.7 x 10.25 cm)
Total Displacement
148.5 in
3
(2.434 liters)
Combustion Type Direct Injection
SAE Net Intermittent (SAEJ1349) HP / rpm
(kW / rpm)
48.9 HP @ 2700 rpm
(36.5 kW @ 2700 rpm)
Maximum Torque / Rotating Speed
117 ft-lb @ 1600 rpm
158.6 Nm @1600 rpm
Maximum Bare Speed: 2900 ± 50 rpm (No load)
Idle Speed: 1100 ± 25 rpm
Firing order 1-3-4-2
Direction of Rotation Counter-clockwise (viewed from flywheel side)
Compression Ratio 20.5:1
Fuel: Diesel Fuel No. 2-D or 2-DLS (Low Sulfur)
Lubrication (API Class) CF or higher
Dimensions
(length x width x height)
26.4 x 19.7 x 26.9 inch
(67.1 x 49.2 x 68.3 cm)
Dry Weight
(BB Spec.)
406 lb (184 kg)
Starter motor 12V, 2.0 kW
Generator 12V, 45 Amp
