59
> Change from previous revision
Item Part No. Qty. Description Serial Numbers/Notes
1
REF 1 Handle Assembly See 2.1
2 4254050 1 Control Lever
3 4127340 1 Knob
4 453017 1 Flat Washer, 1/2
5 454025 AR Spring Washer, 1/2
6 366708 2 Bearing, Flanged
7 461381 1 Roll Pin, 3/16 x 13/16”
8 2000067 1 Lever, Brake Cable
9 443110 2 Nut, 3/8-16 Hex
10 446142 1 Lockwasher, 3/8 Heavy
11 400268 1 Screw, 3/8-16 x 1-3/4” Hex Head
12 4258791 1 Cable, 34-1/2” Brake
Eclipse
2
118, 118F Left Side
12 4258791 1 Cable, 34-1/2” Brake
Eclipse
2
122, 122F Left Side
12 4258830 1 Cable, 38-1/2” Brake
Eclipse
2
126 Left Side
13 4258830 1 Cable, 38-1/2” Brake
Eclipse
2
118, 118F Right Side
13 4258790 1 Cable, 40-1/2” Brake
Eclipse
2
122, 122F, 126 Right Side
14 4253551 1 Controller, MCU REFERENCE U5, See 19.1
15 409807 4 Screw, 1/4-20 x 1/2” Thread Cutting
16 4165020 1 Key Switch REFERENCE SW2, See 19.1
17 4131618 1 • Key
18 N/S 1 • Nut, Face
19 4130132 1 Switch, Rocker REFERENCE SW1, See 19.1
20 4253330 1 Cover, Upper Console
21 4260810 1 Decal, Eclipse 2
22 4265172 1 Decal, Key Switch
23 4265171 1 Decal, Reel
24 4265170 1 Decal, Parking Brake
25 402056 4 Screw, #8-32 x 3/8” Slotted
26 4253310 1 Cover, Lower Console
27 445770 2 Nut, 1/4-20 Nylon Insert
28 452004 2 Flat Washer, 1/4
29 461181 1 Groove Pin, 3/16 x 3/4”
ECLIPSE
2
To Next Page
