Jacobsen Eclipse 2 122F - Page 65

65
> Change from previous revision
ECLIPSE
2
Item Part No. Qty. Description Serial Numbers/Notes
1
63305 1 Gen-Set Power Module See 19.1
2 63306 1 Battery Power Module See 20.1
3 4253190 2 Controller, Motor REFERENCE U1, U2, See 19.1
4 800271 8 Screw, #10-24 x 1/2” Pan Head
5 404016 2 Screw, 1/4-20 x 5/8” Truss Head
6 445245 2 Tinnerman Nut, 1/4-20
7 4253595 1 Mount, Power Module
8 400186 2 Screw, 5/16-18 x 7/8” Hex Head Gen-Set Power Module Only
8 400198 2 Screw, 5/16-18 x 2-1/4” Hex Head Battery Power Module Only
9 400196 2 Screw, 5/16-18 x 2” Hex Head Gen-Set Power Module Only
9 400204 2 Screw, 5/16-18 x 3-1/2” Hex Head Battery Power Module Only
10 446136 4 Lockwasher, 5/16 Battery Power Module Only
11 409807 2 Screw, 1/4-20 x 1/2” Thread Cutting
12 4193060 1 Decal, Front Roller Weight
13 4258590 1 Cover, Motor Controller
14 4255550 4 Female Iso Mount Gen-Set Power Module Only
15 4259130 1 Bracket, Controller Cover
16 453009 4 Flat Washer, 5/16
17 4257467 1 Plate, Power Module Mounting
18 4255551 4 Stud, Iso-Mount Gen-Set Power Module Only
19 4265710 1 Resistor, Ceramic REFERENCE R3, See 19.1
20 400058 2 Pop Rivet, 3/16 x 1/2”
21 361139 4 Spacer Battery Power Module Only
22 4257455 1 Kickstand, 18”
Used on 63334, 63335, 63336,
63337, 63343, 63344, 63345, and
63346
22 4247755 1 Kickstand, 22”
Used on 63338, 63339, 63340,
63341, 63347, 63348, 63349, and
63350
22 4257770 1 Kickstand, 26” Used on 63342 and 63351
23 400190 2 Screw, 5/16-18 x 1-1/4” Hex Head
24 452006 4 Flat Washer, 5/16
25 366715 2 Spacer
26 444718 2 Locknut, 5/16-18 Hex Center
27 400268 1 Screw, 3/8-16 x 1-3/4” Hex Head
28 443810 2 Nut, 3/8-16 Hex Jam
29 446142 1 Lockwasher, 3/8 Heavy
30 400410 1 Screw, 1/2-13 x 1-3/4” Hex Head
31 344132 2 Washer, 1/2
32 443118 1 Nut, 1/2-13 Hex
33 444758 2 Locknut, 1/2-13 Hex Center
34 364164 1 Spring, Extension
35 400404 1 Screw, 1/2-13 x 1” Hex Head
36 4264210 1 Decal, Jacobsen
37 306998 2 Lockwasher, #10 Int/Ext Tooth
