Jacobsen Eclipse 2 122F User Manual

67
> Change from previous revision
ECLIPSE
2
Item Part No. Qty. Description Serial Numbers/Notes
1
4253156 1 Frame, L.H. Side Fixed Head
Eclipse
2
118, 122, and 126
1 4253154 1 Frame, L.H. Side Floating Head
Eclipse
2
118F and 122F
2 4253155 1 Frame, R.H. Side Fixed Head
Eclipse
2
118, 122, and 126
2 4253157 1 Frame, R.H. Side Floating Head
Eclipse
2
118F and 122F
3 4257453 2 18” Crossbar
Eclipse
2
118 and 118F
3 4247754 2 22” Crossbar
Eclipse
2
118, 122, and 126
3 4257470 2 26” Crossbar
Eclipse
2
126
4 434030 8 Screw, 3/8-16 x 7/8” Hex Socket
5 64163-04 8 Flat Washer, 3/8
6 4127931 1 Decal, Patent
7 4117466 1 Decal, 96 dBA Noise
8 4169640 1 Decal, Danger
9 REF 1 Serial Plate
10 800710 2 Screw, 5/16-18 x 1” Hex Flange
Eclipse
2
122, 122F, and 126
11 4258190 2 Bracket, Handle Mount
Eclipse
2
122, 122F, and 126
12 400192 1 Screw, 5/16-18 x 1-1/2” Hex Head
Eclipse
2
118F and 122F Only
13 441672 1 Carriage Bolt, 5/16-18 x 2-1/2”
Eclipse
2
118F and 122F Only
14 441688 1 Carriage Bolt, 5/16-18 x 3-1/2”
Eclipse
2
118F and 122F Only
15 4273518 1 Spindle Mount
Eclipse
2
118F and 122F Only
16 548911 5 Nut, 5/16-18 Hex Flange
Eclipse
2
118F and 122F Only
17 445802 1 Nut, 5/16-18 Nylon Insert Hex
Eclipse
2
118F and 122F Only
18 400200 2 Screw, 5/16-18 x 2-1/2” Hex Head
Eclipse
2
118F and 122F Only
19 453009 8 Flat Washer, 5/16
Eclipse
2
118F and 122F Only
20 4255870 1 Limit Bracket
Eclipse
2
118F and 122F Only
21 332844 2 Spring, Compression
Eclipse
2
118F and 122F Only
