75
> Change from previous revision
ECLIPSE
2
Item Part No. Qty. Description Serial Numbers/Notes
1
4175221 1 Rear Roller - 18”
Used on 63336, 63345, 63337, 63346
1 1004990 1 Rear Roller - 22”
Used on 63340, 63349, 63341, 63350
2 4175220 1 • Shaft, 18”
Used on 63336, 63345, 63337, 63346
2 3010422 1 • Shaft, 22”
Used on 63340, 63349, 63341, 63350
3 3010286 2 • Seal
4 3010712 2 • Bearing
5 4168727 1 Roller Mount - 18”
Used on 63336, 63345, 63337, 63346
5 4136994 1 Roller Mount - 22”
Used on 63340, 63349, 63341, 63350
6 4203300 1 Grass Catcher, 18” Floating Head
Used on 63336, 63345, 63337, 63346
6 4239563 1 Grass Catcher, 22” Floating Head
Used on 63340, 63349, 63341, 63350
7 352726 2 Bushing
8 453023 8 Flat Washer, 1/4
9 446128 4 Lockwasher, 1/4 Med.
10 443102 4 Nut, 1/4-20 Hex
11 400108 4 Screw, 1/4-20 x 3/4” Hex Head
12 4140152 1 Mount, Left Side Catcher
13 4140151 1 Mount, Right Side Catcher
14 471221 1 Grease Fitting, 1/4-28 90°
15 460312 4 Hairpin
16 366317 1 Rod End, 3/8-24
17 4104720 1 O-Ring, Motor
18 4261470 1 Motor, Brushless Bi-Directional Reference M2, See 19.1
19 4167400 1 Plate, Motor Adapter
20 4169040 1 Rod, Panhard, 18”
Used on 63336, 63345, 63337, 63346
20 4138778 1 Rod, Panhard, 22”
Used on 63340, 63349, 63341, 63350
21 360893 1 Rod End
22 4140166 2 Pin, Threaded
23 434024 4 Screw, 5/16-18 x 3/4” Socket Head
24 434029 3 Screw, 1/4-20 x 3/4” Socket Head
25 443110 2 Nut, 3/8-16 Hex
26 443112 1 Nut, 3/8-24 Hex
27 445785 1 Nut, 3/8-24 Left Hand Hex
28 471214 2 Grease Fitting
29 446142 5 Lockwasher, 3/8 Heavy
30 453011 5 Flat Washer, 3/8
31 463029 1 Key, Woodruff
32 845279 1 Seal, O-Ring
33 REF 1 Reel Assembly See 10.1
34 4156930 2 Screw, 3/8-24 x 1” Special
35 2812384 1 Coupler
36 4261071 1 Bracket, Panhard Mount
37 444762 2 Locknut, 3/8-16 Hex Center
38 434030 1 Screw, 3/8-16 x 7/8” Hex Socket
39 417242 1 Fitting, Relief
40 400264 1 Screw, 3/8-16 x 1-1/4” Hex Head
41
