79
> Change from previous revision
ECLIPSE
2
Item Part No. Qty. Description Serial Numbers/Notes
1
4170204 1 Frame, 18” Reel
Used on 63336, 63345, 63337, and
63346
1 5002577 1 Frame, 22” Reel
Used on 63340, 63349, 63341, and
63350
2 400192 8 Screw, 5/16-18 x 1-1/2” Hex Head
3 446142 1 Lockwasher, 3/8 Heavy
4 4225504 1 15 Blade, 18” Left Hand Reel Used on 63337 and 63346
4 4225505 1 15 Blade, 22” Left Hand Reel Used on 63341 and 63350
4 4170220 1 11 Blade, 18” Left Hand Reel Used on 63336 and 63345
4 5001101 1 11 Blade, 22” Left Hand Reel Used on 63340 and 63349
4 5001099 1 9 Blade, 22” Left Hand Reel Optional Reel
4 5003053 1 7 Blade, 22” Left Hand Reel Optioanl Reel
5 1004756 1 Bearing Housing
6 500534 1 • Bearing, Cup and Cone
7 336962 1 • Seal, Grease
8 471214 1 • Grease Fitting
9 471242 1 • Vent Fitting
10 445795 8 Nut, 5/16-18 Spiralock Flange
11 304745 1 Washer
12 458013 1 Snap Ring
13 367164 1 Spacer
14 2811055 1 Backing, 18” Bedknife
14 2000068 1 Backing, 22” Bedknife
15 See Chart 1 Bedknife
16 4252470 AR Screw, 1/4-20 x 1/2” Bedknife Package of 100 Screws
17 315298 2 Wheel Bolt, 7/16 x 3/4”
18 412503 4 Screw, 3/8-16 x 1-1/4” Square Head
19 400294 1 Screw, 3/8-24 x 1” Hex Head
20 453009 4 Flat Washer, 5/16
21 1000480 1 Bearing Housing
22 500534 1 • Bearing, Cup and Cone
23 336962 1 • Seal, Grease
24 471214 1 • Grease Fitting
25 471242 1 • Vent Fitting
26 5002151 1 Spring, Compression
27 364900 1 Nut, Reel
28 453011 1 Flat Washer, 3/8
29 163892 1 Seal
To Next Page
