Jacobsen Eclipse 2 122F - Page 93

93
> Change from previous revision
ECLIPSE
2
Item Part No. Qty. Description Serial Numbers/Notes
68668 1 Battery Case Does Not Include Batteries
1
4105660 1 • Screw, 5/16-18 x 1-1/4” Nylon
2 452004 2 • Flat, Washer 1/4
3 4105800 1 • Fuse, 50A Reference F1, See 19.1
4 447214 1 • Lockwasher, 5/16 Internal
5 443106 1 • Nut, 5/16 Hex
6 2811664 2 • Cable
7 2811662 1 • Main Cable
8 366984 1 • Grommet
9 2811663 2 • Cable, Jumper
10 403741 8 • Screw, #8-32 x 5/8” Hex Head
11 444306 8 • Nut, 8-32 Hex
12 446112 8 • Lockwasher, #8 Heavy
13 4101600 2 • Strap, Battery Case
14 4245270 1 • Gauge, Battery Reference U4, See 19.1
15 2811221 1 • Lid, Battery Case Includes Decals
16 455058 2 • • Flat Washer, 1/4
17 444708 2 • • Locknut, 1/4-20, Center Lock
18 2811220 1 • • Handle, Battery Case
19 404022 2 • • Screw, 1/4-20 x 1” Truss Head
20 4170001 1 • • Decal, Danger
21 453023 8 • Flat Washer, 1/4
22 2809762 1 • Battery Case, Lower Half
23 408851 8 • Screw, 1/4-20 x 3/4” Hex Self Tap
24 444304 2 Nut, #6-32 Hex
25 N/S 4 Battery, 12V Reference B1, B2, B3, B4, See 19.1
26 402006 2 Screw, #6-32 x 1/2” Slotted Round
27 450419 2 Flat Washer, #6
