4 CONTROLS
8
To prevent fuel spill,
only fill to filler neck
!
CAUTION
D
10
10
10
30
30
10
12
14
16
1. Do not operate tractor with horn sounding. Horn will sound to warn of overheated engine or hydraulic system.
See instructions in operators manual to properly clean the radiator or oil cooler and check fluid levels.
2. When implement becomes clogged, disengage power and stop engine before cleaning.
3. Keep hands, feet and clothing away from power driven moving parts.
4. Do not ride on machine or allow passengers unless seat is provided.
5. Keep all shields in place.
6. Stop engine for all servicing, adjustments, or fluid level changes.
7. Read manual thoroughly before operating machine.
8. Do not shift between 2WD / 4WD while tractor is moving
!
CAUTION
10
20
30
40
0
AA
A
B
C
D
E
F
G
H
H
I
J
K
L
M
N
O
P
Q
R
S
T
U
V
W
X
Y
Z
A Steering Tilt Lever
B Differential Lock
C Service Brake
D Traction Pedal
E Parking Brake
F Ground Pressure
G Seat Tilt knob
H Transport Latches
I Throttle Lever
J Left Wing Lift/Lower Lever
K Front Lift/Lower Lever
L Right Wing Lift/Lower Lever
M Horn / Test Switch
N PTO Switch
O Wing Mower Switch
P Front Mower Switch
Q Light Switch (Optional)
R 2WD / 4WD Switch
S Cruise Control Switch
T Tachometer
U Fuel Gauge
V Volt Meter
W Hour Meter
X Circuit Breakers
Y Temperature Gauge
Z Glow Plug Switch
AA Ignition Switch
