Jacobsen Kubota D1105-E4B User Manual

103
> Change from previous revision
TR320
Item Part No. Qty. Description Serial Numbers/Notes
1
002993013 3 Lubricator, M6
2 4140077 1 Center Pivot Bracket, LH
3 4140078 1 Center Pivot Bracket, RH
4 4397726 2 Bumper Yoke
5 686530 1 26” Yoke Weldment, RH
6 686532 1 26” Yoke Weldment, LH
7 687826 1 26” Yoke Weldment, Center
8 694539 2 UK Pivot Arm Bracket, LH
9 694540 2 UK Pivot Arm Bracket, RH
10 695990 2 Yoke Spacer Center Plate
11 001399032 6 Hex Nut, 1/2-20
12 001599052 18 Washer, .526/.506 x 1-1/4 12GA
13 002193318 6 Nylon Bush, 40 x 30 x 40
14 4139374 6 Spacer, 1/2 x 3/4 x 1/2
15 450868 4 Hex Socket Screw, M8 - 1.25 x 35 Grade 12.9
16 452436 4 Hex Nut, M8
17 456010577 6 Hex Screw, 1/2 - 20 x 1.1/2
