Jacobsen LF 3810 User Manual

3 CONTROLS
6
3CONTROLS
3.1 ICONS ___________________________________________________________________
WARNING
Never attempt to drive the tractor unless you have read the Safety & Operation Manual and
know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the location and
purpose of all the controls and gauges before operating this tractor.
Read Manual
High Low
Engine Throttle
Reel Rotation
2-WD 4-WD
Forward Reverse
Drive
Travel
Off Run
Engine
Start
Glow Plugs
Forward
(Cut)
Reverse
(Backlap)
Coolant Temperature
Fuel
Reels
Lower Raise
Lights
Hour Meter
GreenSentry Switch
On Off/Test
D
On Off
Coolant Level
Cold
Hot
Hydraulic Oil Level
Hydraulic Oil Filter
Head Light
Work Light
Reels
Enable Disable
Engine Oil Pressure
Lubrication
Left
Center
Right
Reel Control
! !
