SPECIFICATIONS 4
en-12
4.2 DIMENSIONS AND WEIGHTS ________________________________________________
LF550 / LF570 LF557 / LF577
A - Width of Cut 100 inch (254.0 cm) 140 inch (355.6 cm)
B - Maximum Width 115 inch (292.1 cm) 145 inch (368.3 cm)
C - Transport Width 87 inch (220.9 cm)
D - Height ROPS frame in the vertical position 88 inch (223.5 cm)
E - Height ROPS frame folded 61 inch (155.2 cm)
F - Total length cutting with grass catchers 120 inch (304.8 cm)
G - Total length transport 120 inch (304.8 cm)
H - Wheel Base 62 inch (157.5 cm)
J - Front Wheel Track 72 inch (182.9 cm)
K - Rear Wheel Track 43 inch (109.2 cm)
L - Maximum Height Canopy 93 inch (236.2 cm)
Weight of unit, hydraulic and fuel tanks filled,
reels lifted. Tier 4 Interim D1803 Engine
LF550 2WD: 2946 lb. (1336 kg)
LF550 4WD: 3277 lb. (1486 kg)
LF570 2WD: 3036 lb. (1377 kg)
LF570 4WD: 3367 lb. (1527 kg)
LF557 2WD: 3164 lb. (1435 kg)
LF557 4WD: 3495 lb. (1585 kg)
LF577 2WD: 3399 lb. (1542 kg)
LF577 4WD: 3730 lb. (1692 kg)
Weight of unit, hydraulic and fuel tanks filled,
reels lifted. Tier 4 Final D1803 Engine
LF550 2WD: 3036 lb. (1377 kg)
LF550 4WD: 3367 lb. (1527 kg)
LF570 2WD: 3126 lb. (1418 kg)
LF570 4WD: 3457 lb. (1568 kg)
LF557 2WD: 3254 lb. (1476 kg)
LF557 4WD: 3585 lb. (1626 kg)
LF577 2WD: 3489 lb. (1583 kg)
LF577 4WD: 3820 lb. (1733 kg)
Weight of unit, hydraulic and fuel tanks filled,
reels lifted. Tier 4 Interim V2403 Engine
LF550 2WD: 3192 lb. (1448 kg)
LF550 4WD: 3523 lb. (1598 kg)
LF570 2WD: 3282 lb. (1489 kg)
LF570 4WD: 3698 lb. (1677 kg)
LF557 2WD: 3410 lb. (1547 kg)
LF557 4WD: 3741 lb. (1697 kg)
LF577 2WD: 3645 lb. (1653 kg)
LF577 4WD: 3976 lb. (1803 kg)
Weight of unit, hydraulic and fuel tanks filled,
reels lifted. Tier 4 Final & Stage 5 V2403 Engine
LF550 2WD: 3282 lb. (1489 kg)
LF550 4WD: 3613 lb. (1639 kg)
LF570 2WD: 3372 lb. (1530 kg)
LF570 4WD: 3788 lb. (1718 kg)
LF557 2WD: 3500 lb. (1588 kg)
LF557 4WD: 3831 lb. (1738 kg)
LF577 2WD: 3735 lb. (1694 kg)
LF577 4WD: 4066 lb. (1844 kg)
Weight of fuel in tank 122 lb. (55 kg)
Tire Specifications
Front Wheel Rear Wheel
Tire Size Type Tire Pressure Tire Size Type Tire Pressure
26.5 x 14-12 Ultra Chevron 4 Ply 12 psi (0.83 BAR) 20 x 10-8 Grassmaster 4 Ply 12 psi (0.83 BAR)
