SPECIFICATIONS 2
en-9
2.4 CUTTING UNITS ___________________________________________________________
Type ................................Three Fully Floating Decks
Width:
Front Deck ................64 in. (162.5 cm)
Wing Decks...............42 in. (106.7 cm)
Cutting Width:
Front and both Wings134 in. (340.3 cm)
Front and one wing... 99 in. (251.4 cm)
Front only.................. 64 in. (162.5 cm)
Drive ............................... Hydraulic Motors
Cutting Height................. 1.00 - 5.5 in. (2.5 - 14.0 cm)
2.5 WEIGHTS AND DIMENSIONS ________________________________________________
Dimensions: Inches (cm)
Length........................................................... 144 (365.7)
Height (ROPS)................................................ 84 (213.4)
Height (ROPS Folded)................................. 63.5 (161.3)
Height (Cab Installed) ................................... 102 (259.1)
Wheel Base.................................................. 67.8 (172.2)
Width - Transport Position............................ 93.5 (237.5)
Width - Mowing Position................................ 139 (353.0)
Ground Clearance............................................. 7 (17.8)
Turning Radius................................................ 33 (83.8)
Weight: Lbs. (kg)
Hydraulic and Fuel Tanks Full
69177.......................................................... 4080 (1851)
69177 (Cab Installed).................................. 4606 (2089)
Hydraulic tank full, Fuel Tank Empty
69177.......................................................... 3958 (1796)
69177 (Cab Installed).................................. 4481 (2034)
2.6 ACCESSORIES AND SUPPORT LITERATURE __________________________________
Contact your area Jacobsen Dealer for a complete listing of accessories and attachments.
Accessories
Mulcher Kit.................................................................. 69174
Care Free Tire Kit.....................................................2811453
Canopy / Sunshade .................................................... 68127
Light Kit................................................................... 4207582
Blade Balancer........................................................JAC5016
Cab ...........................................................4265112/4265113
Cab Accessories................................................................. l
Brush/Sweeper ................................................................... u
Snow Blower....................................................................... s
l Contact Customer Service for Cab Accessories
u Contact: M-B Company
1200 Park Street Box 148
Chilton, WI 53014-0148
Phone 888-558-5801/920-898-4203
Fax 920-898-4588
Support Literature
Safety, Operation, & Maintenance Manual ..............4289794
Parts Manual............................................................4289795
Diesel Engine Parts Catalog....................................4192126
Operator Training Video (DVD)................................4219160
CAUTION
Use of other than Jacobsen authorized parts and accessories may cause personal injury or damage to the
equipment.
