CONTROLS 4
GB-7
10
12
14
16
A Tilt Steering Lever
B1 Parking Brake Lock
B2 Parking Brake Release
C Parking Brake Pedal
D Mow Speed Stop
E Traction Pedal - Forward
F Traction Pedal - Reverse
G Seat Adjustment
H Hydraulic Oil Cap
I Hydraulic Oil Light
J Fuel Cap
K Fuel Level Gauge
L Backlap Switch
M Hour Meter
N Water Temperature Gauge
O Volt Meter
P Engine Oil Light
Q Horn
R 2WD / 4WD Switch
S Raise / Lower Joystick
T Reel Switch
U Light Switch
V Ignition Switch
W Throttle
X Parking Brake Light
Y Fuse Blocks
Z Horn Switch
