*Add 1/4" to this dimension when roughing-in for 3-wall niche.
Note: 1. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
2. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
*Añada 1/4" a esta medida al instalar las unidades de 3 muros.
Nota: 1. Las medidas que aparecen adentro de la unidad representan el corte necesario en el piso para la instalación de desagüe/rebosadero.
2. Todas las medidas vienen en pulgadas; para convertirlas a milímetros, multiplique por 25.4.
STELLARIA
55"
55"
27"
27"
39 1/2"
36 1/2"
44 1/2"
36 1/2"
12" x 4"
- 2" x 4" Stud
(Right-hand only as shown.)
(Mano derecha (como mostrado) solamente)
(Left- and right-hand determined by pump location.)
(Es izquierda o derecha según la ubicación de la bomba.)
- 2" x 4" Stud
TARA
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
ROUGHING-IN REFERENCE
DIAGRAMAS EN PLANTA DE INSTALACIONES
12
CORNER BATHS CUTOUT
DIAGRAMA EN PLANTA DE TINAS De ESQUINA
STELANO
58"
(1473 mm)
22-7/8"
(581 mm)
48-5/8"
(1235 mm)
90° 90°
58"
(1473 mm)
22-7/8"
(581 mm)
3" RADIUS CORNERS
(5 PLACES)
CAPELLA
25-1/2"
(648 mm)
58"
(1473 mm)
49-9/16"
(1157 mm)
58"
(1473 mm)
25-1/2"
(648 mm)
25-1/2"
(648 mm)
58"
(1473 mm)
45-9/16"
(1157 mm)
TARA
58"
(1473 mm)
25-1/2"
(648 mm)
STELLARIA
53"
(1346 mm)
25-3/4"
(654 mm)
2-3/4"
(70 mm)
59"
1499 mm
R = 70"
53"
(1346 mm)
25-3/4"
(654 mm)
(Universal)
- 2" x 4" Stud
TARA WITH INTEGRAL SKIRT
TARA CON FALDÓN INTEGRADO
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Note: Unless otherwise specified, units are produced with left or right-hand versions.
Nota: Si no se ha especificado de otra manera, las unidades se ofrecen con la bomba a la izquiera o a la derecha.
