Jacuzzi Avalanche Owner's Manual

4
Parts for Avalanche
1
9
FIG.
NO.
PART NO. DESCRIPTION
FIG.
NO.
NO. PIÈCE DESCRIPTION
1
2
3
4
5
6
7
8
9
10
10a
11
42-3614-02-R
42-3671-02-R
42-3677-06-R
14-4282-05-R
43-3098-06-R
9193-4182-R
42-2852-05-R
42-2998-00-R
42-3610-00-R
42-3611-01-R
23-4836-05-R
23-4835-06-R
23-4834-07-R
23-4953-02-R
47-0380-47-R
42-3570-04-R
42-3569-07-R
42-2125-14-R
42-2123-16-R
42-2952-04-R
42-2951-05-R
42-2955-01-R
42-2954-02-R
42-3741-08-R
47-3742-07-R
42-3743-06-R
42-3744-05-R
14-4387-09-R
14-4388-08-R
14-4389-07-K
14-4390-04-R
Handle
Ring-Lok
Cover Latch
Air Bleed Knob w/ O-Ring Boot #5
O-ring Boot (See #4)
Pressure Gauge
Cover AV40
Cover AV60
Cover AV80
Cover AV100
Lifting Strap AV40
Lifting Strap AV60
Lifting Strap AV80
Lifting Strap AV100
O-Ring
AV40 Grid 7”W x 12”L (2 Req.)
AV40 Grid 8-1/2”W x 12”L (4 Req.)
AV60 Grid 7”W x 18”L (2 Req.)
AV60 Grid 8-1/2”W x 18”L (4 Req.)
AV80 Grid 7”W x 24”L (2 Req.)
AV80 Grid 8-1/2”W x 24”L (4 Req.)
AV100 Grid 7”W x 30”L (2 Req.)
AV100 Grid 8-1/2”W x 30”L (4 Req.)
AV40 Grid Assembly
AV60 Grid Assembly
AV80 Grid Assembly
AV100 Grid Assembly
Wiper Tie Rod AV40
Wiper Tie Rod AV60
Wiper Tie Rod AV80
Wiper Tie Rod AV100
12
13
14
15
16
17
18
19
20
14-4314-07-R
31-1731-07-R
31-1695-01-R
31-1733-05-R
42-3544-07-R
42-3559-09-R
31-1687-08-R
31-1689-09-R
31-1688-00-R
42-3546-05-R
42-3673-00-R
42-3662-00-R
47-0328-00-R
43-3092-02-R
47-0224-05-R
Nut
Top Extenstion AV40
Top Extenstion AV60
Top Extenstion AV80
Support Plate
Wiper Plate
Spacer AV40
Spacer AV60 and AV100 (2 Req. for AV100)
Spacer AV80
Manifold
Filter Body 2” NPT Connections
Filter Body 1-1/2” NPT Connections
O-Ring 1-1/2”
Plug 2” w/ O-Ring 47-0228-01
Plug 1-1/2” w/ O-Ring 47-0224-05
