16
It is the responsibility of the installer/owner to ascertain
compliance with specific local regulations prior to installa-
tion.
Jacuzzi Europe S.p.A. gives no guarantee in this respect
and refuses all responsibility regarding compliance of the
installation carried out.
Technical Features
Sienna Experience (
1) includes:
- a control unit, called “Spa-Pak” (
1, A).
NOTE: it is possible to additionally add a spa-pak “booster kit”
(optional,
2-2a, n°33) to be connected to the one
supplied as standard; refer to the relative documenta-
tion.
- the balance tank (
1, V/V1) which, once connected, is
required to hold water that overflows when users get into the
tub. Its nominal capacity is 1,000 litres (operating with about
800-850 litres).
- the Hot tub (
1, C), is to be connected, with hoses, to the
“Spa-Pak”, the balance tank and the drain.
MAXIMUM ABSORPTION FOR THE SYSTEM
SINGLE-PHASE TOP
• version with heater
• version with exchanger
THREE-PHASE
WEIGHTS
Heat exchanger (optional)
- MAX primary circuit temperature .............................................................50 °C
- Connections.....................................................................................................................3/4”
- Primary circuit flow rate ..............................................................................38 l/min
- Primary pressure drop.....................................................................0,271 m H
2
O
Components
Components and the necessary connections for setting up the
system are described below (see
2-2a).
Hot tub and hosing
1 overflow channel with grid
2 buttons
2a box for connection of buttons
3 low-point drain with gate valve
4A1+4B1 to the balance tank (overflow lines)
4A2+4B2 to the balance tank (overflow lines)
4C1/4C2 from the overflow channel (overflow lines)
5 hydromassage pump suction lines
6 hydromassage pump delivery lines
7 filtering suction line
8 suction line from the balance tank
9 filtering return line
10 blower line (optional)
11 connections to the water system
12 perimeter metal supports
Spa-pak
13, 13a
Electric wiring box
14 optional - 14b: heater or 14a: heat exchanger
15 hydromassage pumps
16 filtering pump
17 blower
18 quartz sand filter
19 safety switch
20 temperature sensor
21 flow switch (models with heater)
Balance tank
22 water loading/filling solenoid valve (3/4”)
23 level switches
24 check valve
25 gate valve (for emptying)
26 pre-filters
27 overflow
28, 29 ground drainage points
30 gate valves (for system maintenance)
31 gate valves (for suction balancing)
Net weight
average fill
maximum
water volume
Total
max. weight
kg
litres
litres
kg
~200
~ 1430
~ 1760
~1960
resting surface
concentrated load on
resting surface
m
2
kg/m
2
~0,95
~2063
MINIPOOL
max weight
at full load
ground resting surface
ground load
LOWERED
RETAINER TUB (V1)
SPA-PAK
kg
m
2
kg/m
2
~ 900
~ 1,8
~ 500
~ 285
~ 1,1
~ 260
RETAINER TUB (V)
~ 925
~ 1,2
~ 770
50/60
Power supply
(three-phase)
Volt
45
17
(j)
Hertz Ampere
kW
(*): special standard (not valid for Europe)
(j): max. power absorption
Total consumption electric heater
(12 kW) +pumps+lights
13
5
(j)
Ampere
kW
Total consumption only pumps and
lights (heat exchanger version)
220 - 240 3~
(*)
50/60
26
17
(j)
8
5
(j)
380 - 415 3N~
50/60
Power supply (x)
Volt
19,5 (k) 4,25 (j)
Hertz Ampere
kW
(k): at 230 V - (j): power absorption
(x): see the “electrical preparations” chapter
Total consumption
hydro + filtering
220-240 ~
50/60
Power supply (x)
Volt
25,5 (k)
5,75 (j)
Hertz Ampere
kW
Total consumption
hydro + filtering + heater (3
kW
)
220-240 ~
