J-400
7.0 Power Requirements
Jacuzzi
®
spas are designed to provide optimum performance and
exibility of use when connected to their maximum electrical service.
They are congured at the factory. The most common electrical
connections are listed below:
 All North American 60 Hz Models only: These models come set for
50A logic. If you prefer, your qualied technician can perform a logic
modication that allows the spas to operate on a different electrical
service (see table footnotes below).
North American J-425/J-460/J-465/J-470/J-480 Models (60 Hz)
Voltage: 240 VAC 240 VAC 240 VAC
Max. Current Draw: 23A 36A 45A
Frequency: 60 Hz 60 Hz 60 Hz
Number of Wires: 3 3 3
Circuit Breaker (2-Pole): 30A* 50A** 60A***
*
In 30A conguration, the heater will not operate while either jets
pump is running.
**
In 50A conguration, the heater will operate when one jets pump
is running, but will not operate while both jets pumps are running.
This is the factory setting.
***
In 60A conguration the heater will operate while both jets pumps
are running.
North American J-495 Models (60 Hz)
Voltage: 240 VAC 240 VAC 240 VAC
Max. Current Draw: 23A 36A 45A
Frequency: 60 Hz 60 Hz 60 Hz
Number of Wires: 3 3 3
Circuit Breaker (2-Pole): 40A* 50A** 60A***
*
In 40A conguration, the heater will not operate when any jets
pump is running.
**
In 50A conguration, the heater will operate when one jets pump
is running, but will not operate when two or more jets pumps are
running. This is the factory setting.
***
In 60A conguration the heater will operate when two jets pump
are running, but will not operate when all three jets pumps are
running.
