JET/AIR CONTROLS J-495
J-495
Massage Selectors (1-2)
• Massage selector 1 diverts jets pump Nº 2
output between jets groups 1a-1b.
• Massage selector 2 diverts jets pump Nº 1
output between jets groups 2a-2b.
IX Jet Flow Control Valve (3)
• Valve (3) controls output to footwell IX Jet
when jets pump Nº 3 is running.
Jets Without Massage Selector Controls
(4)
• Jets (4) are always on when jets pump 3 is
running.
Waterfall Selector (5)
• Waterfall selector (5) controls circulation
pump output to waterfall.
J-495
Air Controls Operation
• Rotate air controls 1-5 to add air to desig-
nated jet groups.
• Center footwell IX Jet (6) draws air at all
times when jets pump Nº 3 is running. This
jet has no air control.
The hot tub specications are subject to change without prior notice.
The hot tub specications are subject to change without prior notice.

Jacuzzi J-470 Specifications

General

Pumps	2
Waterfalls	2
Shell Material	Acrylic
Cabinet Material	Synthetic
Dimensions	38 in
Water Capacity	450 gallons
Lighting	LED lighting system
Warranty	5 years
