1. ProTouch™ Control Panel
2. Waterfall Control Valve
3. Air Control Valves (4 ea.) Introduce Air to Specified Jet Groups
4. Optional Audio System Speaker (4 ea.)
5. Adjustable Pillows (4 ea.)
6. Lighted Cup Holder (4 ea.)
7. Massage Selectors (2 ea.) Controls Specified Jet Groups
8. Waterfalls (2 ea.)
9. FX Jets (12 ea.)
10. FX Rotational Jets (6ea.)
11. FX Small Jets (8 ea.)
12. Filter/Skimmer Grill
13. MX2 Jets (3 ea.)
14. FX Large Rotational Jets (6 ea.)
15. NX2 Jets (4 ea.)
16. RX Jets (6 ea.)
17. Footwell Filter Suction Covers (4 ea.)
18. Waterfall Filtration Return
19. PX Jets (6 ea.)
20. Lighted IX Jet
21. Gravity Drain/Heater Input/CLEARRAY Return Fitting
22. Lighted IX Jet Flow Control Valve
23. Optional Audio System
CHARACTERISTICS AND CONTROLS J-480
