Jacuzzi J - 480 Use, Installation And Maintenance Instructions

38
JET/AIR CONTROLS J-465
1a
1b
1b
1b
4
4
4
44
1
2
3
3
2
1
1
2
2
2 2
2
3
3
3
1
3
2
J-465
Massage Selector (1)
• Massage selector 1 diverts pump 1 output
between jets groups 1a-1b.
Massage Selector (2)
• The massage selector 2 separates the
pump 1 output from well IX jet.
Waterfall Selector (3)
• Waterfall selector 3 controls circulation
pump output to waterfall.
Jets Without Massage Selector
Controls (4)
• Jets 4 are always on when jets pump 2 is
running.
J-465
Air Controls Operation
• Rotate air controls 1-3 to add air to desi-
gnated jet groups.

Jacuzzi J - 480 Specifications

General

Circulation Pump	Yes
Stereo	Optional
Voltage	240V
Amperage	50A
Pump 1	2.5 HP
Pump 2	2.5 HP
Lighting	LED
Heater	SmartHeat™ Titanium Heater
