Electrical Diagram
SOL. VALVE
FOR DRAINAGE
Cable to electric pump
3
2
1
4
Power supply cable
(220/240V)
Cable to level probe
(12V)
Cable to electric heating
(220/240V)
ELECTRIC
CONTROL
BOX
SOL. VALVE
FILLING
SOL. VALVE
WATERFALL
SOL. VALVE
SHOWER
SOL. VALVE
TURBOMASSAGE
(12V)
(12V)
COMPUTER
CABLE
(12V)
CABLE TO
SOLENID
VALVES
(220/240V)
14
14
16
