Jacuzzi J-LX Series User Manual

46
A3 Checking Voltages to Devices
Device voltages are often measured at the circuit board to determine whether the board or device is bad. If the
circuit board delivers voltage when device operation is called, the circuit board is probably good and the prob-
lem lies with the device or the wiring to the device. The following voltage chart shows operating voltages for
all major hot tub components. Voltage is considered good if within ±10% of the listed value. Refer to appendix
pages 50-53 for your specic circuit boards test point locations.
For all North American 60 Hz
J-LX/J-LXL
2011-2013 J-335/J-345/J-355/J-365/J-375 Models
Device Test Points Voltage ±10%
Pump 1 (Low Speed) 5 and 6 240 VAC
Pump 1 (High Speed) 5 and 7 240 VAC
Pump 2 (High Speed) 8 and 9 240 VAC
Circulation pump 14 and 15 240 VAC
Water heater 12 and 13 240 VAC
CLEARRAY or Ozone generator (optional) 16 and 17 240 VAC
2011-2013 J-315/J-325 Models
Device Test Points Voltage ±10%
Pump 1 (Low Speed) 5 and 6 240 VAC
Pump 1 (High Speed) 5 and 7 240 VAC
Circulation pump 14 and 15 240 VAC
Water heater 12 and 13 240 VAC
CLEARRAY or Ozone generator (optional) 16 and 17 240 VAC
2011-2012 J-230/J-270/J-280 Models with Circulation Pump
Device Test Points Voltage ±10%
Pump 1 (Low Speed) 5 and 6 240 VAC
Pump 1 (High Speed) 5 and 7 240 VAC
Pump 2 (N/A on J-230) 8 and 9 240 VAC
Circulation pump 14 and 15 240 VAC
Water heater 12 and 13 240 VAC
CLEARRAY or Ozone generator (optional) 16 and 17 240 VAC
J-210 Models
2011-2013 J-315/J-325 Models
Device Test Points Voltage ±10%
Pump 1 (Low Speed) 5 and 6 120 VAC
Pump 1 (High Speed) 5 and 7 120 VAC
Water heater 12 and 13 120 VAC or 240 VAC*
CLEARRAY or Ozone generator (optional) 16 and 17 120 VAC
*Depends whether hot tub is connected to 120 VAC or 240 VAC supply
J-230/J-235/J-245/J-270/J-275/J-280 Models without Circulation Pump Models
Device Test Points Voltage ±10%
Pump 1 (Low Speed) 5 and 6 240 VAC
Pump 1 (High Speed) 5 and 7 240 VAC
Pump 2 (N/A on J-230) 8 and 9 240 VAC
Water heater 12 and 13 240 VAC
CLEARRAY or Ozone generator (optional) 16 and 17 240 VAC
