Jacuzzi JAG - Section 4. Install the Cleaner; Submerge in the Pool

6
JACUZZI
®
JAG ROBOTIC CLEANER
1. Plug power supply into a GFCI outlet (Ground
Fault Circuit Interrupter) (Figure 1). Power Supply
must be 5ft. from the pool's edge.
Figure 1. Plug into Power Supply
2. Straighten the oating cable. Lift the ap on
the power supply and plug in the power cable
(Figure2).
Figure 2. Connect the Power Cable
SECTION 4. INSTALL THE
CLEANER
CAUTION
To prevent damage to the cleaner, be sure to adhere to
the following guidelines:
• Remove the cleaner from the pool after the cleaning
cycle is completed.
• Store cleaner out of direct sunlight out of direct
sunlight or inclement weather.
• Never lift the cleaner out of the pool by the oating
cable.
• Take additional care when lifting the cleaner out of the
pool. It becomes heavier when lled with water.
• Always remove the cleaner from the pool before super
chlorinating or adding acid.
• Do not handle cleaner while it is in operation.
IMPORTANT
• Always make sure the cleaner head is fully
submerged before you begin operation.
• Clean out debris after each cleaning cycle.
• Do not leave your cleaner in the pool on a
permanent basis.
• At the end of each cycle, remove the cleaner from
the pool.
• Start at the cleaner head and untangle any coils in
the cable before storing the cleaner.
4.1 SUBMERGE IN THE POOL
1. With the control box plugged into a GFCI outlet,
spread the oating cable across the pool deck
until you reach the middle of the pool length.
NOTE: For optimal patterning and reduced tangling, the
floating cable should enter the water near the middle
of the pool length.
