7
OWNER'S MANUAL
12 ft / 4 m
Midpoint of the long side of pool
Figure 3. Pool Entry Point for Optimal Patterning
2. Submerge cleaner vertically and turn upside
down until the bubbles stop to remove any air
trapped inside
(Figure 4)
.
3. When the bubbles stop, allow the cleaner to sink
to the bottom of the pool.
Figure 4. Submerge and Remove Trapped Air
4. Verify the cleaner is sitting right-side up on the
bottom of the pool. Remove additional air if the
cleaner is still oating.
5. Spread all of the oating cable carefully in the
pool, ensuring there are no kinks or coils.
Useonly as much cable as you need to reach the
farthest wall. This can help prevent cable tangling
(Figure 5).
Figure 5. Spread Floating Cable to Prevent
Tangling
4.2 START / STOP CLEANING
1. Press On/O button to begin or interrupt cleaner
operation (Figure 6).
ON / OFF
Figure 6. Begin Cleaning
2. Press SELECT button to choose between SMALL
POOL and LARGE POOL. Cleaning duration for
a small pool is 1 hour; for a large pool, duration is
2 hours (Figure 7).
3. Cleaner will begin to move.
= 1 Hour Shut-off
= 2 Hour Shut-off
Figure 7. Select Pool Size and Duration
To Next Page
