Jacuzzi K272000AF - Cutout; Roughing-In

ENGLISH
Motor
Overflow
25-1/2"
(648 mm)
58"
(1473 mm)
45-9/16"
(1157 mm)
58"
(1473 mm)
25-1/2"
(648 mm)
TARA CORNER CUTOUT
Right Hand
Drain
59"
Ref.
90˚
90˚
GALLERY CORNER,
Left Hand
22-5/8"
(575 mm)
90˚
90˚
3" RADIUS
CORNERS
(5 PLACES)
22-5/8
"
(575 mm)
58"
(1473 mm)
58"
(1473 mm)
50"
(1270 mm)
Ref.
57"
Drain
Overflow
Motor
CAPELLA 60 &
25-1/2"
(648 mm)
58"
(1473 mm)
58"
(1473 mm)
25-1/2"
(648 mm)
45-9/16"
(1157 mm)
CAPELLA 60 W/ FRONT LEFT MOTOR/PUMP
(Motor/Pump position not shown.)
Ref.
59"
Drain
Overflow
90˚
90˚
CUTOUT- CORNER BATHS
17
Jacuzzi Whirlpool Bath K272000AF 7/06
25-1/2"
(648 mm)
58"
(1473 mm)
45-9/16"
(1157 mm)
58"
(1473 mm)
25-1/2"
(648 mm)
TARA CORNER CUTOUT
Left Hand
Drain
59"
Ref.
Motor
Overflow
90˚
90˚
ROUGHING-IN REFERENCE (CORNER)
TARA™, Left Hand
- 2" x 4" Stud
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Motor
Service
Access
Opt.
Service
Access
- 2" x 4" Stud
TARA™, Right Hand
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Motor
Service
Access
Opt.
Service
Access
- 2" x 4" Stud
TARA™ WITH INTEGRAL SKIRT
- Junction Box
27-1/4"
35"
44"
60"
60"
46"
27-1/4"
35"
14" x 4"
Motor
(Right-hand only as shown)
ROUGHING-IN
CUTOUT
GALLERY CORNER,
Right Hand
22-5/8"
(575 mm)
90˚
90˚
3" RADIUS
CORNERS
(5 PLACES)
22-5/8"
(575 m
m
)
58"
(1473 mm)
58"
(1473 mm)
50"
(1270 mm)
Ref.
57"
Drain
Overflow
Motor
NOTE: 1. The overall dimensions are nominal with a tolerance of +0 and -1/4" (6,4 mm).
2. Service Access dimensions given are minimum. Service access is still required for units that do not have pre-installed Pump/Motor.
3. Measurements inside each unit represent cutout in floor to allow for drain/overflow.
4. All measurements are in inches. To convert to millimeters, multiply inches by 25.4.
5. Not all export units come with pre-installed Pump/Motor.
