Jadac THINGMAGIC M6e - Environmental and Mechanical Specifications

ThingMagic M6e User Guide 8
www.JADAKtech.com
Environmental Specifications
Operating Temperature
The M6e module may be considered as a single electronic component. It is designed so that all the internal
components have safe margins to their thermal limits when the heat spreading plate (bottom, non-labeled
side) does not exceed 70°C. The heat spreading plate temperature must not exceed 70° C. Heat sinking
will be required for high duty cycle applications.
When heat spreading plate reaches 70°C, the RF Shield (top, antenna connector side) may exceed 70°C,
which is acceptable.
Tag Reading
Transmit Mode=Power Save
+30 5.8 5.0 +/- 5% 1060
Tag Reading
Transmit Mode = DRM + PreDistortion
+30 6.2 5.0 +/- 5% 1200
Tag Reading
Transmit Mode = DRM
+17 and below 4 5.0 +/- 5% 800
No Tag Reading (M6e idle)
Power Mode = FULL
N/A 0.35 5.0 +/- 5% 60
No Tag Reading (M6e idle)
Power Mode = MINSAVE
N/A 0.12 5.0 +/- 5% 20
No Tag Reading (M6e idle)
Power Mode = SLEEP
N/A 0.005 5.0 +/- 5% 1.0
Boot N/A 0.12 5.0 +/- 5% 20
Shut Down N/A < 0.001 5.0 +/- 5% < 200uA
In Rush Current and Power, M6e
Power up and/or any state change
N/A 7.5 5.0 +/- 5% 1500 Max
1
Power consumption is defined for TTL RS232 operation. Power consumption may vary if the USB interface is con-
nected.
2
Power consumption is defined for operation into a 17dB return loss load or better. Power consumption may
increase, up to 8.2W, during operation into return losses worse than 17dB and high ambient temperatures.
M6e Power Consumption
Operation
Power/Transmit Mode
RF Transmit
Power
Setting
(dBm)
Max
Power
1
(Watts)
Voltage
(Volts)
Current
(mA)
