ThingMagic M6e User Guide 11
www.JADAKtech.com
Authorized Antennas
This device has been designed to operate with the antennas listed below, and having a maximum gain of 6
dBiL. Antennas not included in this list or having a gain greater than 6 dBiLare strictly prohibited for use
with this device. The required antenna impedance is 50 ohms.
M6e-A Authorized Cables
The following table contains the cable loss values for authorized shielded coaxial cables provided by
ThingMagic:
M6e Authorized Antennas
Vendor Model
Linear Gain
1
(dBi)
ThingMagic ANT-WB-6-2025 5.1
ThingMagic ANT-NA-9025 (obsolete) 3.4
ThingMagic ANT-NB-7-2031 6.0
ThingMagic ANT-WB-12-2043 6.0
ThingMagic ANT-WB-10-2048 6.0
1
These are circularly polarized antennas, but since most tag antennas are linearly polarized, the
equivalent linear gain of the antenna should be used for all calculations.
M6e-A Authorized Cables
Cable Description ThingMagic Part Number Insertion Loss
6' RTNC to RTNC Cable CBL-P6 0.8 dB
12' RTNC to RTNC Cable CBL-P12 (obsolete) 1.5 dB
20' RTNC to RTNC Cable CBL-P20 2.4 dB
20' RTNC to RTNC Plenum Cable CBL-P20-PL (obsolete) 2.4 dB
25' RTNC to RTNC Cable CBL-P25 (obsolete) 3.0 dB
